General:
This reversing camera is specially dedicated for VAG vehicles. The inconspicuous, robust camera with Sony CCD lens simply replaces the trunk release handle. Just easy remove the existing trunk release handle and replace it with the reversing camera. The camera is complete including plug and play cable kit which allows easy plug and play installation. The camera is waterproof according to the IP67 certification level.
Features:
- 1/3” SONY CCD lens
- 600 TV lines
- Lens angle 170 degrees
- Waterproof according to IP67 certification level
- Black Light Compensation
- Display in mirror image
- Automatic color correction
- Waterproof according to IP67 certification level
- Black Light Compensation
- Display in mirror image
- Automatic color correction
The following is provided in the set:
- Audi reversing camera NTSC
- Video extension cable 5 meter (RCA)
- Installation manual
- Invoice
- Warranty
Additional information:
- With a multimedia interface or video interface it is possible to connect the camera with the original navigation system, ask for the possibilities.
- Concerns a high-end SONY CCD lens, so no cheap CMOS lens
Technical features:
- IP rating: IP68 (Water proof)
- Image Sensors : Colour 1/3"SONY CCD
- TV System: NTSC
- Effective Pixels: NTSC 752x582
- Sensing Area: 4.9 × 3.7 mm
- Horizontal Resolution: 600TV Line
- Horizontal Sync. Frequency: 15.625 / 15.734 kHz
- Vertical Sync. Frequency : 50/60 Hz
- Video output: 1Vp-p,75Ohm
- Gamma Consumption: 0.45
- Auto Gain Control: Automatic
- Back Light Compensation: Automatic
- S/N Ratio: Better than 48dB
- Lens Angle: 170 ° (Degrees)
- Current Consumption: 150mA
- Power Supply: DC +12V (10%)
- Operating Temperature: -20 C to +70 C
- Storage Temperature : -40 C to +80 C
- Connection: RCA
- Image: Mirror
1 Serie F40
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
3 Serie G20
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
5 Series F90 M5
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
5 Series G30
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
5 Series G31
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
5 Series G38
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
X1 Serie
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
X5M Serie F95
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
X5 Serie G05
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
X6 Serie G06
2019-20..
- Signal
CVBS - CVBS signal
NTSC - Parking line wire
- Mirror wire
- Extension cable included
BMW 1-serie 2019-20..
BMW 3-serie G20 2019-20..
BMW 5-serie G30 2019-20..
BMW X1-serie
BMW X5-serie (G05) 2019-20..
BMW X6-serie (G06) 2019-20..
Note:
-Not compatible with X2 (has logo boot handle)
-Not compatible with Z4 (G29)
-Not compatible with X3-serie (G01) 2019-20..
