Heavy duty AHD ball camera; Front/Rear/Side; 1920 x 1080 (NTSC)
Features
- 2M SONY CMOS AHD Color FHD Sensor
- Vibration & impact resistant housing
- All view direction applicable (via rotary key)
- IP69K Waterproof rating
- 160 degrees lens (Wide field of view)
- IP69K Waterproof rating
- 160 degrees lens (Wide field of view)
- NTSC - 30fps
- WDR (Wide Dynamic Range)
- High End Night View (0.0Lux) with 8* LEDs
- WDR (Wide Dynamic Range)
- High End Night View (0.0Lux) with 8* LEDs
- Anti-glare & ghost
- Voltage range (5V-32V)
- Extreme Temp. Durability
- Extreme Temp. Durability
Operating: -30°C ~ 60°C
Storing Temp. : -40°C ~ 80°C
Storing Temp. : -40°C ~ 80°C
- Din metal screwlock connector
- Front/Rear/Side mounting
- CE-mark
- FCC-mark
- 2 Year warranty & Support
EXCLUSIVE CAMERA FEATURES
Highest Quality lens
2M SONY CMOS AHD Color FHD Sensor 1920 x 1080 (NTSC)
IR leds
The camera is equipped with 8* IR nightvision leds.
-Auto ON/OFF by a brightness detecting sensor
-Progreesive Brightness adjustment
-Wider & Longer illuminating range by a patented designed front glass
Mirror & Unmirror switch
The camera is equipped with an mirror & Unmirror magnetic switch
- switch not installed is Unmirror view
- switch installed is mirror view
Microphone
Built-in microphone located on the back to minimize the wind noise
Ball rotary
All view direction applicable just by rotating the camera in the ball bracket.
Metal screw lock
Water- & shock proof 4-pins mini din screw lock connector.
Ignition proof (+15)
It is possible to connect the powersupply to an ignition feed (+15), because we use the highest quality camera.
In this way you are able to watch the camera also in DRIVE gear or via manual selection.
NOTES
- We recommend that the installation will be performed by a qualified specialist
- Check also the other tabs for "Compatibility" - "Package contents" - "Product specifications"
LEGAL NOTICE
Please check before purchase if it is aloud to install this camera and it wont affect your MOT.
Not available
COMPATIBILITY
Universal use
Only for rear installation
NOTES
- CVBS signal is NTSC
PACKAGE CONTENTS
The following is provided in the set:
CAM-HD-Q6HD
Package:
-
AHD 1080 camera with metal screwlock connector: 1x
-
Screw set: 1x
-
Rubber pad with self-adhensive tape: 1x
-
Installation instructions: 1x
