RC-PSA-DS7

Rear camera interface PSA NAC & Opel NAVI5.0 9"_10" & 12"

Call for Price
Datasheet Where to buy
DESCRIPTION

General
The NavInc NAVconnect interfaces allow for connecting video sources to the original Citroen & Peugeot system (10" & 12").
The interface is equipped with various options such as; 1* Front camera input & 1* Rear camera input.

Example video


Features
- 1x Rear camera input
- 1x Front camera input (with auto switch OFF)
- iPAS Parking lines
- Adjustubele parking lines via OSD menu
- 3 Year warranty & Support


EXCLUSIVE INTERFACE FEATURES
Features:
- Reverse Camera input
- Front camera input
- Image retention while driving
- Adjustable parking lines
- OSD menu


CAMERA FEATURES
Rear camera input with Parking guidelines
Rear camera input with parking guidleines option.

The guidelines makes it much easier to determine the distance to the object you are driving towards.
The guidelines are adjustable horizontal as well as vertical so the lines can be adjusted to the car.


Front camera input
Front camera input which will be selected after leaving the reverse gear.
Via the OSD menu you can select show time:
3 sec
5 sec
10 sec
15 sec

Picture In Picture (PiP)
Overlay from the original parking sensors.

NOTES
- We recommend that the installation will be performed by a qualified specialist
- Check the other tabs for "Compatibility" - "Package contents" - "Product specifications"


LEGAL INFORMATION
The driver ofthe vehicle should not be inferred from the motion images. In many countries, watching movies while driving is prohibited. Therefore we accept no responsibility for material or personal injuries, directly or indirectly, due to installation of the interface modules.

Interface and Software basic information:
The NavInc interfaces are no navigation systems or screens to replace the navigation system. The NavInc interfaces enable the possibilities to connect different Audio/Video sources to the navigation system.

Manufacturers create adjusted software and hardware versions, options and enhancements which ensures that the compatibility of the products cannot be guaranteed 100%. Compatibility lists are based on customer feedback and experiences and will constantly be updated for optimal customer support.
Compatibility

DS3

2020-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    Smart Touch 12.0"
  • Coding needed
    No

DS4

2020-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    Smart Touch 12.0"
  • Coding needed
    No

DS7

2020-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    Smart Touch 12.0"
  • Coding needed
    No

208

2019-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    No
  • Head-unit
    i-Cockpit 10"
  • Coding needed
    No

2008

2019-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    No
  • Head-unit
    i-Cockpit 10"
  • Coding needed
    No

3008

2019-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    No
  • Head-unit
    i-Cockpit 10"
  • Coding needed
    No

508

2019-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    No
  • Head-unit
    i-Cockpit 10"
  • Coding needed
    No

Corsa-e

2019-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    NAVI5.0 - 10.0"
  • Coding needed
    No

C3 Aircross

2021-20..

  • Note: LVDS not available - iPAS not tested
  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp
  • Touch support
    No
  • Head-unit
    Connect NAV-system 9.0"
  • Coding needed
    No

Ë-C4

2021-20..

  • Note: car not tested yet
  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    12" (not tested)
  • Coding needed
    No

C5-X

2021-20..

  • Note: car not tested yet
  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    12" (not tested)
  • Coding needed
    No

C4-E

2021-20..

  • Note: car not tested yet
  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    12" (not tested)
  • Coding needed
    No

Corsa-e

2019-2021

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    NAVI5.0 - 10.0"
  • Coding needed
    No

Grandland

2021-20..

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    NAVI5.0 - 10.0"
  • Coding needed
    No

DS7

2020-2022

  • Rear camera input
  • Front camera input
  • RGB input
  • LVDS input
  • HDMI input
  • A/V input
  • A/V output
  • Activation
    OEM & Trigger
  • Signal
    APIX - HSD
  • Open head-unit
  • CVBS signal
    NTSC
  • Guide lines
  • I-DRV
  • Picture in Picture (PiP)
  • iPAS lines
  • R-gear select
    Lamp & CAN
  • Touch support
    Yes
  • Head-unit
    Smart Touch 12.0"
  • Coding needed
    No
Extra Information
COMPATIBILITY
CAR
This kit is compatible with the following models:

Peugeot - Connect nav 10.0"
Citroen - Connect nav 9.0"
Citroen - Connect nav 10.0"
DS NAC – Smart Touch 12.0"
Opel NAVI5.0 (NAC) – 10”


NOTE


AUDIO OUTPUT

The interface inserts ONLY video signals into the infotainment. It is essential to have an Aux-in, when using audio from an external AV source.

CVBS

Only compatible with NTSC sources.

LVDS

Not available

SCREEN

Interface is compatible with 9"_10” & 12” monitors

FRONT CAMERA

The front camera input will automatically switch after leaving the reverse gear.

You can set the display time in seconds via the OSD menu (1-15 sec).

OEM REAR CAMERA

The interface does not switch back automatically to the OEM rear camera input when the reverse gear is engaged.

GUIDELINES

iPAS & Static lines are available via the interface OSD menu

iPAS

iPAS option is available (moveable grid lines)

PIP

PiP option is available for original parking sensor overlay  (Picture in Picture)

REAR SELECT CAMERA INPUT

When interface won’t respond on reverse CAN, please use the 12V reverse detection wire (grey wire)

INSTALLATION

We recommend that the installation will be performed by a qualified specialist












Packaging
PACKAGE CONTENTS
The following is provided in the set:

RC-PSA-DS7
Package:
  1. Power cable (HARETC0250 K): 1x
  2. Multi cable (HARETC0324): 1x
  3. LVDS cable (HLCCA0005): 1x
  4. Remote (REMOTE0001): 1x
  5. IR eye (HIRCAB0002) 1x
  6. Interface module: 1x
  7. Manual: 1x
  8. Service instructions: 1x
